This project consists of 23 modern townhouse units located in West Abbotsford, BC.
Fraser Point is a four-storey concrete tilt-up commercial building complete with contemporary interiors and cutting-edge building systems.
We designed this four storey, 65,000 sq.ft. recreation vehicle dealership consisting of a showroom with significant glazing areas opening onto a major collector street in Abbotsford, BC. This project utilizes several key construction technologies including precast and CIP concrete, steel framing as well as mass timber structural elements. The project includes wash bays, multiple service bays, office spaces, and customer amenity areas. It is currently nearing completion and occupancy.
This development consists of five (5) commercial retail buildings.
Krahn Group was hired by Wesgroup Properties to provide design and engineering services for this two building multi-tenant concrete tilt-up industrial development on a 8.5 acre site located just north of the Hwy #1 and Mt. Lehman interchange. The site offers high exposure to the Mt. Lehman area for industrial users.
South on 16th Premium is a limited collection of only 22 townhomes situated between Grandview Heights and White Rock. All units have double side by side garage and are all approx. 1,500 sq.ft.
This development consists of a 203,175 sq.ft. concrete tilt-up multi dock loading warehouse/distribution center in the Tilbury industry park in Delta, BC, Canada. Tilt wall panels to the exterior of the building in conjunction with two internal brace lines provide the lateral support system. The gravity system is provided by the tilt wall panels to the perimeter of the building with internal structural steel framing consisting of beams and columns (supported off reinforced concrete foundations) providing support to the open web steel joists and metal roof decking. The ground floor consists of an 8” thick slab on grade. During construction a 50 ft. wide section of the perimeter floor slab was placed as the casting bed for the tilt wall panels. The remainder of the floor slab was placed at the end of the project after the underground services were completed and the building was fully watertight. This allowed for the easy addition of the trench and catch basins to the floor slab which were required by the single tenant user who was not identified until well into the project build. The tilt wall panels to the front elevation of the building consist of spandrel panel legs at the locations of the window openings to allow for the continuation of the spandrel glazing system as required for the architectural design of the building. The erection of the tilt wall panels was carried out in three separate lifts which allowed for a third of the building to be erected, structural steel and metal decking installed up to the internal brace lines allowing for the tilt wall braces to be removed and used for the next phase of the tilt.
Krahn Group designed this four storey, 65,000 sq.ft. recreation vehicle dealership consisting of a showroom with significant glazing areas opening onto a major collector street in Abbotsford, BC. This project utilizes several key construction technologies including precast and CIP concrete, steel framing as well as mass timber structural elements. The project includes wash bays, multiple service bays, office spaces, and customer amenity areas. It is currently nearing completion and occupancy. This project is being delivered via the Design/Build methodology. The Krahn Group of Companies has provided all integrated design disciplines on this project.
The Krahn Group was hired by Spire Construction to design this two-storey concrete tilt-up strata warehouse building on 32nd Avenue in Surrey, BC.
Krahn Group provided design services for this process grading facility for Golden Valley Foods Ltd. Located in the Mt. Lehman area, this facility contains office, processing and warehouse storage areas.
